Vizio XVT553SV Manual do Utilizador

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 1 www.VIZIO.com Dear VIZIO Customer, Congratulations on your new VIZIO XVT423S

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 10 www.VIZIO.com Chapter 1 Setting Up Your HDTV Finding a Location for Your HDTV The power consumption of

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 11 www.VIZIO.com Wall Mounting your HDTV Your HDTV can be mounted on the wall for vi

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 12 www.VIZIO.com Chapter 2 Basic Controls and Connections Front Panel 1. Remote Control Sensor—Point th

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 13 www.VIZIO.com Rear Panel Connections 1. ETHERNET—Connect an Ethernet cable to

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 14 www.VIZIO.com Side Panel Connections 1. USB 1, 2, and 3:  Reserved for future functions.  Service

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 15 www.VIZIO.com Remote Control Buttons Basic TV Functions INPUT—Press to cycle thr

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 16 www.VIZIO.com —(DASH)—Press to insert a dash between the main and sub-channels. For example, digital c

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 17 www.VIZIO.com Making it Your Universal Remote The Setup App that runs when you f

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 18 www.VIZIO.com Chapter 4 Getting Started Your VIA-enabled HDTV has a built-in Setup App that plays wh

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 19 www.VIZIO.com Chapter 5 Using your HDTV for the first time Connecting to the Inte

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 2 www.VIZIO.com Important Safety Instructions Your HDTV is designed and manufactured to operate within de

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 20 www.VIZIO.com Viewing Digital TV Program Information When the channel is changed an information heade

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 21 www.VIZIO.com Exploring VIZIO Internet Apps (VIA) Press the VIA

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 22 www.VIZIO.com Chapter 6 Connecting Equipment Which Video Connection Should I Use? You have six option

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 23 www.VIZIO.com Connecting Your Cable or Satellite Box Using HDMI (Best) Cable an

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 24 www.VIZIO.com Using Component Video (Better) 1. Turn off your HDTV and Cable/Satellite box. 2. Conn

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 25 www.VIZIO.com Connecting Your DVD Player Using HDMI (Best) DVD players that h

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 26 www.VIZIO.com Using Component Video (Better) 1. Turn off the power to your HDTV and DVD player. 2.

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 27 www.VIZIO.com Connecting Coaxial (RF) Using Your Antenna or Digital Cable for Sta

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 28 www.VIZIO.com Connecting a Home Theater System Using RCA Connecting the cable

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 29 www.VIZIO.com COMPUTERCOMPUTER3. Change the input on your Home Theater to optica

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 3 www.VIZIO.com  The wall socket should be installed near your HDTV and easily acc

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 30 www.VIZIO.com Ethernet Connection The Ethernet function on your HDTV is used to access the Internet

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 31 www.VIZIO.com Chapter 7 Using VIA Connecting to the Internet VIA delivers popula

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 32 www.VIZIO.com Using VIZIO Internet Apps (VIA) VIA puts the best of the web right on your TV screen,

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 33 www.VIZIO.com Deleting Apps 1. Press the VIA button. 2. Press ◄ or ► to select t

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 34 www.VIZIO.com Switching Profiles 1. Press the VIA button. 2. Press ◄ or ► to select the Profile App, a

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 35 www.VIZIO.com Chapter 8 Adjusting Your HDTV Settings Using the On-screen Displa

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 36 www.VIZIO.com Wide Menu Select how the picture displays on the screen. As you select an option, you w

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 37 www.VIZIO.com CC (Closed Caption) Menu Adjust closed caption options. Analog Clo

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 38 www.VIZIO.com Picture Picture Mode Choose from Standard, Movie, Game, Vivid, Football, Golf, Basketba

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 39 www.VIZIO.com Advanced Picture To select the options in the Advanced Picture sub

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 4 www.VIZIO.com Television Antenna Connection Protection External Television Antenna Grounding If an outs

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 40 www.VIZIO.com Audio Adjust audio options including balance, equalizer, and advanced audio settings. Au

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 41 www.VIZIO.com Audio Control Select which device the VIZIO remote control adjusts

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 42 www.VIZIO.com Tuner When you first turned on your HDTV you scanned for channels using the Setup App.

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 43 www.VIZIO.com Name Input This feature makes it easier for you to recognize the d

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 44 www.VIZIO.com Device Setup This feature allows you to add devices to your HDTV and control them with y

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 45 www.VIZIO.com Parental Controls If you want to restrict certain channel and prog

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 46 www.VIZIO.com USA-Movie Note: When Rating Enable is OFF, USA-Movie Rating adjustments are not enabled

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 47 www.VIZIO.com Change PIN (Password) Enter a new, 4-digit password using the numbe

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 48 www.VIZIO.com PIP Menu Your TV features PIP mode so you can watch two pictures at the same time. One p

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 49 www.VIZIO.com Network Menu When you first turned on your HDTV you set up your net

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 5 www.VIZIO.com Advisory of the DTV Transition The nationwide switch to digital tel

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 50 www.VIZIO.com More Access Points Select this option to show more wireless networks in the list. Select

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 51 www.VIZIO.com Help Menu System Info Display the technical information including

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 52 www.VIZIO.com Chapter 9 Maintenance and Troubleshooting Cleaning the TV and Remote Control 1. Remov

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 53 www.VIZIO.com Issue Solution Power is ON but there is no image on the screen / B

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 54 www.VIZIO.com Issue Solution cover the entire screen/ Black bars on the top or side of the image  C

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 55 www.VIZIO.com Audio Troubleshooting Issue Solution No audio  Press Volume +

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 56 www.VIZIO.com Remote Control Troubleshooting Issue Solution The remote control will not work  Point

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 57 www.VIZIO.com Media Viewer Troubleshooting Issue Solution USB device is not reco

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 58 www.VIZIO.com Compliance Caution: Always use a power cable that is properly grounded. Use the AC cords

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 59 www.VIZIO.com Chapter 10 Specifications Product specifications may change without

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 6 www.VIZIO.com Table of Contents Important Safety Instructions...

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 60 www.VIZIO.com XVT423SV Specifications Non-Operating Temperature: -20°C~50°C, Relative Humidity: 10~70

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 61 www.VIZIO.com XVT473V Specifications Power Input IEC Connector for direct power

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 62 www.VIZIO.com XVT553V Specifications Features 1080P FHDTV, MEMC, 120Hz + Scanning B/L Panel, HDMI v1.4

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 63 www.VIZIO.com Preset PC Resolutions If connecting to a PC through the RGB PC inpu

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 64 www.VIZIO.com Resolution through RGB Input If your PC supports VESA Reduce Blanking timing via the VG

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 65 www.VIZIO.com Warranty ONE-YEAR LIMITED WARRANTY ON PARTS AND LABOR (Covers units

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 66 www.VIZIO.com Index 16:9 ...36

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 67 www.VIZIO.com Canadian English Rating...46 Canad

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 7 www.VIZIO.com Using Optical (S/PDIF) ...

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual 8 www.VIZIO.com Audio Troubleshooting......

VIZIO XVT423SV/XVT473SV/XVT553SV User Manual Version 4/26/2010 9 www.VIZIO.com Opening the Package Your HDTV and its accompanying accessories are c
